    Outdoor External P10 Led Display High Contrast Ratio Large Viewing Angle

    Ask Lasest Price
    Brand Name : REISS
    Model Number : P10
    Certification : ROHS FCC CE EMS UL
    Price : Negotiable
    Payment Terms : L/C, D/A, , Western Union, MoneyGram
    Delivery Time : 7-10 Work days
    • Product Details
    • Company Profile

    Outdoor External P10 Led Display High Contrast Ratio Large Viewing Angle

    P10 Sports Perimeter Stadium led stadium advertising boards


    Led Sport Cricket Live digital Scoreboard,P10 rgb Star Sports Led Display Screen outdoor


    High Brightness
    Durable outdoor SMD led with 5500-7000 nits high brightness to match different
    occasions;
    High Uniformity & Contrast
    High quality led lamp and mask for super bright display and high contrast image;
    Anti-UV Module
    Anti-Oxidation module frame with anti-UV material to protect high temperature
    ultraviolet radiation;
    IP65 Waterproof Protect
    With waterproof tape around the modules, prevent the rain and dust;
    Reliable
    Over 100000 working hours for longtime use;
    Multi-Control Systems
    Synchronous and asynchronous systems for option.


    Application

    Products have been widely used in airports, stations, ports, stadiums, banks, schools, churches, etc.




    Module
    Pitch/mm
    P10
    Module size/mm
    320*160
    Density of pixel/(dots/m2)
    10000dots
    Pixel composition
    1R1G1B
    Led encapsulation
    SMD3535
    Resolution of module
    32*16
    Screen
    Optimum viewing distance
    10-150m
    View angle / °
    120H,120V
    Max power consumption
    1000W/sqm
    Size of cabinet/mm
    960X960
    Resolution of cabinet
    96*96

    Driving method

    1/4 scan
    Refresh rate Hz/S
    ≥960
    Luminance of white balance
    ≥6500cd/sqm
    Operation of Environmental
    Temperature/℃
    below 30 to above 50
    Protective grade
    IP65
    Working voltage
    110-220 VAC/+/- 10%
    Grey scale/color
    14bits
    Brightness adjustment
    4096 levels of each color(manually),
    100 levels of each color(automatically)
    Input signal
    RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
    Control system
    Linsn / Nova(sending card, receiving cards and Hubs)
    Average of non-failure life
    >10,000h
    Life span
    >100,000h
    Functionless dot rate
    <0.0001
